Original price was: 4,700.00৳ .4,550.00৳ Current price is: 4,550.00৳ .
High-Performance Injection Mortar for Heavy Load Anchoring Resin for Cracked & Non-Cracked Concrete
Post-installed rebar connections in existing concrete
Shear connectors, concrete layer jointers
Heavy steel structures, rail fixings, tall shelving systems
Seismic reinforcement & retrofit
Anchorings in water-filled or diamond-drilled holes
Temporary or removable fixings (in conjunction with internal threaded anchors)
Wood-concrete or wood-steel connections (approval for glued laminated timber)
The Fischer FIS EM Plus 390 S is a premium two-component epoxy injection mortar designed for secure anchoring in both cracked and non-cracked concrete. Backed by ETA approvals and engineered for high load capacity, this epoxy mortar is ideal for structural reinforcements, rebar connections, seismic retrofit, heavy steel anchoring, and demanding construction environment applications.
Why choose FIS EM Plus 390 S?
Optimized resin formulation yields enhanced load values in both cracked and non-cracked concrete.
Approved for diamond-drilled and water-filled drill holes, offering versatility under varied site conditions.
Validated for seismic zones with performance categories C1 and C2, ensuring resilience under dynamic loads.
Reliable performance at low temperatures (down to –5 °C) supports cold weather installations.
ETA assessment guarantees a service life of 100 years, and expert reports even extend this to 120 years.
Capable of anchoring rebar diameters from 8 mm up to 40 mm, accommodating a wide range of structural requirements.
Whether for retrofits, expansion joints, or high-load anchoring in concrete structures, FIS EM Plus 390 S delivers robust and durable bonding.
Post-installed rebar connections in existing concrete
Shear connectors, concrete layer jointers
Heavy steel structures, rail fixings, tall shelving systems
Seismic reinforcement & retrofit
Anchorings in water-filled or diamond-drilled holes
Temporary or removable fixings (in conjunction with internal threaded anchors)
Wood-concrete or wood-steel connections (approval for glued laminated timber)
FIS EM Plus 390 S comes as a dual-component cartridge (resin + hardener). The two materials remain separated until extrusion through the included static mixer (FIS MR Plus), ensuring correct mixing only at point of use.
The mortar is injected bubble-free from the base of the drilled hole, fully bonding the anchor rod (or rebar) to the concrete wall surfaces and sealing the bore hole. In push-through installation, the annular gap between the anchor and the fixture is filled with the epoxy mortar.
Anchors such as Fischer FIS A threaded rods or internal threaded anchor RG M I (for temporary fixings) are compatible, giving flexibility in the design of embedment depth and load transfer.
Superior adhesion and load performance, even in cracked concrete
Durable under environmental and structural stress
Works under wet or flooded conditions — approved for use in water-filled drill holes
Suitable for seismic zones (C1, C2 performance)
Usable in low temperatures (down to –5 °C)
ETA-backed service life of 100 years (up to 120 years via expert report)
Simplified installation with pre-measured cartridges and static mixer
Compatible with various anchor rods and systems
Drill hole to specification (diameter, depth)
Clean thoroughly (blow & brush / vacuum)
Insert static mixer and begin injection from bottom
Insert anchor or rebar while rotating slightly
Allow curing (refer to curing times in technical datasheet)
Apply design loads after full cure
Below is a structured technical specification sheet suitable for engineering reference, datasheets, catalogs, or inclusion in marketing materials.
| Property | Value |
|---|---|
| Product name / variant | Fischer FIS EM Plus 390 S |
| Packaging | 390 ml cartridge + 2 × static mixer FIS MR Plus |
| Usage | Chemical anchoring / injection mortar for cracked & non-cracked concrete |
ETA-17/0979, ETA-17/1056: European Technical Assessments for bonding systems in concrete
Service life guarantee: 100 years (with expert report up to 120 years)
Seismic performance categories: C1, C2
Approved for use in diamond-drilled and water-filled holes
Timber anchoring approval (glued laminated timber of spruce, pine, fir)
Suitable for anchorings in sealed surfaces per Water Resources Law (WRL) / official building certificate for water-impermeable concrete
Tested materials: Concrete C20/25 to C50/60, possibly steel-fiber reinforced up to certain fiber content limits
| Property | Testing Standard / Method | Typical Value |
|---|---|---|
| Density | DIN method | 1.4 – 1.6 g/cm³ |
| Linear shrinkage on cure | ASTM D2566 | < 0.01 % |
| Elongation at break | ASTM D695 | ~1.1 % |
| Bond strength after 20 days | ETAG (ETAG assessments) | > 11 MPa |
| Tensile strength (after 1 week) | ASTM D638 | ~51.3 MPa |
| Compressive strength | ASTM D695 | ~98 MPa |
| Compressive modulus | ASTM D695 | ~2,600 MPa |
| Heat deflection temperature | ASTM D648 | ~50 °C |
| Water absorption (14 days) | DIN / ASTM D570 | ~0.18 % |
| UV-resistance | DIN | Not UV resistant (dark grey color) |
| Temperature resistance | DIN | Up to 100 °C |
| Chemical resistance (1 % tenside solution) | DIN |
Note: The epoxy is not UV-resistant; exposure to sunlight may degrade surface properties over time.
Pull-out / bond performance: As per ETA datasheets (use design tables)
Minimum rebar diameter: 8 mm
Maximum rebar diameter: 40 mm
Effective temperature range during installation: –5 °C to +40 °C (some approvals)
Working / curing times: (refer to detailed ETA / technical datasheet)
Anchor embedment variation: Allows variable anchorage depth selection via compatible anchor rods
Bubble-free injection: Mortar is injected from bottom upwards to avoid air voids
From Safety Data Sheet for FIS EM Plus 390/585/1500 S:
Hazard classes / risks:
• Skin corrosion / severe burns (H314)
• Skin sensitization (H317)
• Respiratory irritation (H335)
• Reproductive toxicity (H360F)
• Hazardous to aquatic environment (H411)
Precautionary Measures:
• Wear protective gloves, clothing, eye and face protection
• Avoid inhalation, skin or eye contact
• In case of skin or eye exposure, rinse immediately and seek medical attention
• Use only in well-ventilated areas
• Prevent release to environment
Storage temperature: 5 °C to 25 °C (avoid extremes)
Shelf life / stability: Usually months (check original packaging or manufacturer’s statement)
Disposal considerations: Follow local regulations for hazardous chemical waste
Designers should refer to ETA / national approval documents for project-specific characteristic load tables and safety factors.
Always allow for appropriate safety factors, edge distances, spacing, and embedment lengths per code or design guideline.
For seismic applications, use performance category C1 / C2 data from approved documents.
Where water-filled or diamond-drilled holes are involved, ensure compliance with the product’s approval scope.
For timber anchoring, follow approved design guides for laminated timber types (spruce, pine, fir).
Use appropriate cleaning / hole preparation methods (blowing, brushing, vacuuming) to remove dust and debris for optimal bonding.
